21.5”
Intel® Celeron®
쿼드코어 프로세서
Windows 10 Pro
(Windows 11 옵션)
스캐너
카메라
MSR, SCR
고객이 직접 주문과 결제를 하려면 큰 화면과 응답 속도가 중요하죠.
눈에 보이지 않는 곳까지 믿을 수 있도록 세심하게 준비했어요.
컴퓨터 다루듯 손쉽게 사용할 수 있습니다.
기본적으로 카드사 가맹점 가입을 도와드려요.
유통형, 일반형 스캐너를 선택할 수 있어요.
영수증 용지 교체가 쉽고 수리도 편리합니다.
테이블형, 스탠드형, 벽걸이형, 티켓형 스탠드를 지원합니다.
| K1 (K1-215) | KB1-215 (Barrier Free Kiosk) | |
|---|---|---|
| System | ||
| CPU |
Intel® Processor N100 (6MB Cache, 3.4 GHz Max) Intel® Core™ i3-1220P (12MB Cache, 4.4 GHz Max) |
Intel® Processor N100 (6MB Cache, 3.4 GHz Max) |
| Memory |
N100: DDR4 4 GB (Max 16 GB) i3-1220P: DDR5 8 GB (Max 32 GB) |
N100: DDR4 4 GB (Max 16 GB) |
| Storage | Internal m.2 SATA SSD 128 GB | Internal m.2 SATA SSD 128 GB |
| Operating System | Windows® 10 IoT | Windows® 10 IoT |
| Audio | Realtek ALC897 Codec | Realtek ALC897 Codec |
| Display | ||
| Type | 21.5-inch Color TFT-LCD | 21.5-inch Color TFT-LCD |
| Resolution | 1080 x 1920 | 1080 x 1920 |
| Luminance | 250 (typ.) | 250 (typ.) |
| Touchscreen | Projective Capacitive Touch | Projective Capacitive Touch |
| Response | 22 ms | 22 ms |
| Physical Characteristics | ||
| Electrical | Internal Power Adaptor 100-240 V AV, 50/60 Hz | Internal Power Adaptor 100-240 V AV, 50/60 Hz |
| Dimensions (WxLxH) |
Desktop: 360 x 132 x 800 mm Wall-mounted: 360 x 132 x 800 mm Standing (Basic model): 360 x 132 x 1650 mm |
Desktop: 360 x 195 x 800 mm Wall-mounted: 360 x 195 x 800 mm Standing: 420 x 460 x 1500 mm |
| Weight |
Desktop: 17 Kg Wall-mounted: 14kg Standing (Basic model): 34kg |
Desktop: 17.5 Kg Wall-mounted: 14.5kg Standing: 30.0kg |
| Certification | KC | KC |
| Interface | USB 3.0 x 2, USB 2.0 x 2, VGA x 1, LAN x 1, Serial x 5 (D-SUB 9 Pin x 3, RJ45 x 2), Line Out x 1, Mic x 1 | USB 3.0 x 2, USB 2.0 x 2, VGA x 1, LAN x 1, Serial x 5 (D-SUB 9 Pin x 3, RJ45 x 2), Line Out x 1, Mic x 1 |
| Environment Characteristics | ||
| Temperature |
Operating: 0 to 40℃ Storage: -20 to 60℃ |
Operating: 0 to 40℃ Storage: -20 to 60℃ |
| Humidity | 10 to 90% | 10 to 90% |
| Built-in Peripherals | ||
| Printer |
SPP-200(3-inch, Max. 250 mm/s, Auto Cutter, Serial) - Emulation: BXL/POS™ - Driver/Utility: Windows® Driver, OPOS, Utility - SDK/Plugin: Windows POS SDK |
SPP-200(3-inch, Max. 250 mm/s, Auto Cutter, Serial) - Emulation: BXL/POS™ - Driver/Utility: Windows® Driver, OPOS, Utility - SDK/Plugin: Windows POS SDK |
| Speaker | General dynamic cone speaker, 79 dB | General dynamic cone speaker, 79 dB |
| Options | ||
| Card Reader | Magnetic Stripe Reader, Smart Card Reader | Magnetic Stripe Reader, Smart Card Reader |
| Camera | 2 M (1600 x 1200) | |
| Barcode Scanner | Standard 1D/2D Barcode(640x480 Pixel), Retail 1D/2D Barcode(1280x1080 Pixel) | Standard 1D/2D Barcode(640x480 Pixel) |
| Accessories | ||
| Accessories | Stand, Wall-mount Bracket, POP Bracket | Stand, Wall-mount Bracket, POP Bracket |
Features and specifications are subject to change without prior notice.
21.5”
Intel® Celeron®
쿼드코어 프로세서
Windows 10 Pro
(Windows 11 옵션)
스캐너
카메라
MSR, SCR
21.5 인치의 대형 FHD 화면으로 매장의 분위기와 어울리는 광고 이미지와 메뉴 사진을 보기 좋게 넣을 수 있어요.
카드 결제뿐 아니라 현금 결제까지 다양한 결제 방식으로 편리하게 이용할 수 있어요.
강도 높은 판금으로 도구를 이용한 파손을 방지하고, 이중 잠금장치로 안심하고 사용할 수 있어요.
용지 교체가 쉽고 유지보수는 간편하게 만들었습니다. 용량이 넉넉한 일체형 지폐/동전 수납통을 사용해 현금 수거 횟수도 줄일 수 있어요.
고성능 스캐너로 빠르고 정확하게 상품의 바코드를 인식할 수 있어요.
누구나 사용할 수 있는 친숙한 윈도우 운영체제를 지원하고 대용량 저장공간까지 제공해요.
검증된 전용프린터 탑재로 빠른 속도로 높은 품질의 인쇄를 지원해요.
| System | |
|---|---|
| CPU |
Intel® Processor N100 (6MB Cache, 3.4 GHz Max) Intel® Core™ i3-1220P (12MB Cache, 4.4 GHz Max) |
| Memory |
N100: DDR4 4 GB (Max 16 GB) i3-1220P: DDR5 8 GB (Max 32 GB) |
| Storage | Internal m.2 SATA SSD 128 GB |
| Operating System | Windows® 10 IoT |
| Audio | Realtek ALC897 Codec |
| Display | |
| Type | 21.5-inch Color TFT-LCD |
| Resolution | 1080 x 1920 |
| Luminance | 250 (typ.) |
| Touchscreen | Projective Capacitive Touch |
| Response | 22 ms |
| Physical Characteristics | |
| Electrical | Internal Power Adaptor 100-240 V AV, 50/60 Hz |
| Dimensions (WxLxH) | 524 x 307 x 675 mm |
| Weight | 38 Kg |
| Certification | KC |
| Interface | USB 3.0 x 2, USB 2.0 x 2, VGA x 1, LAN x 1, Serial x 4 (D-SUB 9 Pin x 2, RJ45 x 2), Line Out x 1, Mic x 1 |
| Environment Characteristics | |
| Temperature |
Operating: 0 to 40℃ Storage: -20 to 60℃ |
| Humidity | 10 to 90% |
| Built-in Peripherals | |
| Printer |
BK3-31(3-inch, Max. 250 mm/s, Auto Cutter, Serial) - Emulation: BXL/POS™ - Driver/Utility: Windows® Driver, OPOS, Utility - SDK/Plugin: Windows POS SDK" |
| Barcode Scanner |
Retail 1D/2D Barcode(1280x1080 Pixel) Motion Tolerances: 6m/s Interface: USB Type Field of View: 50˚(H) x 35˚(V) |
| Speaker | General dynamic cone speaker, 79 dB |
| Cash Module | 3 types of banknotes & 2 types of coins acceptor, 1 type of banknote & 1 type of coin dispenser |
| Options | |
| Card Reader | Magnetic Stripe Reader, Smart Card Reader, and more |
Features and specifications are subject to change without prior notice.
